Slewing ring made of aluminium

Ball bearing type LVB

69715L

LVB-0100

Special sizes on request


Unit price: -,- EUR
Price -,- EUR


Description

Franke LVB slewing rings are ready-to-install universal joints with housing rings made of aluminium and integrated wire race bearings. Designed as 4-point bearings, they can withstand equal loads from all directions and are resistant to shocks and vibrations. LVB slewing rings are sealed on both sides. All Franke slewing rings are adjusted to be play-free with preload.

Material

Inner / Outer ring: aluminium, anodized

Ball race rings: hardened and tempered chrome-silicon steel

Rolling element: hardened rolling bearing steel

Cage: polyamide Seal: NBR / alternatively FKM (Viton)

Operating temperature: -20 °C to +80 °C, up to +100 °C for short periods

Peripheral speed: max. 5 m/s, 10 m/s without seal

Grease: Shell Gadus S3 V220 C2

Relubrication: via threaded grease nipple to DIN 3405

Operating temperature

-20 °C to +80 °C, short-term up to +100 °C

Peripheral speed

Max. 5 m/s, without seal max. 10 m/s

Lubricant

Shell Gadus S3 V220 C2

Relubrication

Via grease nipples to DIN 3405
Smooth running
Resilience
Speed
Stiffness
Weight
Price
